Overview of the Leviton Series 2000 Indoor Meter Kit 277/480V 3P4W 200A with 3 Solid Core CTs, 2K480-2SW
You’ll find this Leviton Series 2000 meter kit is designed for precision energy measurement in commercial and industrial applications. It’s packaged as an indoor meter kit rated for 277/480V, 3-phase 4-wire systems, and includes three solid-core current transformers (CTs) sized to support up to 200A service per phase.
What this meter measures
This meter measures kWh as a standard function and can optionally measure demand, which is useful for billing, energy cost allocation, and peak load analysis. You’ll appreciate that it supports both cumulative energy totals and time-based demand metrics when you configure it for demand recording.
Compliance and accuracy
You can rely on the Series 2000 to meet recognized revenue-grade requirements; it’s certified to applicable sections of ANSI C12.1. The meter and CTs are built for accurate billing and energy management, with CT options that meet revenue-grade accuracy classes.
Leviton Series 2000 Indoor Meter Kit 277/480V 3P4W 200A with 3 Solid Core CTs, 2K480-2SW
Key features and specifications
You’ll see a concise set of features that make the 2K480-2SW a practical choice when you need a compact indoor metering solution with modern communications. The combination of isolated pulse output and RS-485 serial port using Modbus Native gives you flexible data export options to connect with most AMR and BAS systems.
| Feature | Details |
|---|---|
| Product Name | Leviton Series 2000 Indoor Meter Kit 277/480V 3P4W 200A with 3 Solid Core CTs, 2K480-2SW |
| Voltage | 277/480V, 3-phase, 4-wire |
| Current Rating | 200A (meter kit) |
| Included CTs | 3 solid-core CTs (revenue grade 0.3 accuracy class, 0.1A secondary) |
| Optional CTs | 1% split-core CTs available |
| Accuracy | Revenue grade 0.3 (meter), CTs accuracy class 0.3; 0.1A secondary |
| Outputs | Isolated Pulse Output, RS-485 Serial Port (Modbus Native) |
| Standards | Certified to applicable ANSI C12.1 standards |
| CT Paralleling | Up to three sets per phase can be paralleled per meter |
| Measurements | kWh standard; demand optional |
| Mounting | Indoor enclosure (kit) |
| Typical Applications | Submetering, tenant billing, energy management, BAS integration |
Electrical ratings
You’ll want to match the meter’s electrical ratings to your service. This kit supports 277/480V systems in the common 3-phase, 4-wire arrangement and is intended for installations up to 200A. If your distribution matches these specifications, the kit will integrate directly; for higher currents you’ll either parallel CTs as allowed or choose a different CT ratio.
Current Transformer (CT) details
The included CTs are solid-core, revenue-grade units with an accuracy class of 0.3 and a 0.1A secondary, which helps ensure billing-level accuracy. If you need easier retrofits without panel shutdown, you can opt for 1% split-core CTs as an alternative, though they trade a bit of convenience for slightly different accuracy characteristics.
Communications and integration
You’ll benefit from two standard outputs: an isolated pulse output for legacy or pulse-counting AMR deployments and an RS-485 serial port using Modbus Native for modern building automation and data logging. That combination means you can integrate the meter into most AMR systems and BAS platforms without needing protocol converters in many cases.
Physical and environmental
This is an indoor meter kit intended to be mounted inside electrical rooms, meter rooms, or equipment cabinets. You’ll need to keep it dry and within the manufacturer’s specified ambient range; the kit is not intended for outdoor exposure unless installed within a suitable enclosure rated for outdoor use.
